| 刀片外形 insert shape | type 型号 | dimension（mm）基本尺寸 | |||||
| φi.c | s | φd | l | r | a° | ||
 | zdet08t2r10 | 6.75 | 2.78 | 2.8 | 8.4 | 10 | 14 |
| zdet1103r12.5 | 8.5 | 3.18 | 2.8 | 10.6 | 12.5 | 14 | |
| zdet13t3r16 | 10.5 | 3.97 | 4.4 | 13.2 | 16 | 14 | |
| zpnt2204r20 | 12.7 | 4.76 | 5.5 | 16.1 | 20 | 11 | |
| zpnt2204r25 | 12.7 | 4.76 | 5.5 | 16.9 | 25 | 11 | |
| zpnt2204r31 | 12.7 | 4.76 | 5.5 | 17.6 | 31.5 | 11 | |
更多产品及牌号推荐，欢迎咨询下载。
for more types and grade recommendation, welcome to contact us or download catalog.
