刀片基本形状 the basic shape of inserts | 型号 type | 基本尺寸 dimension（mm） | |||||
| b | r | l | d | s | |||
 | mgmn | 200-m | 2 | 0.2 | 16 | 1.2 | 3.5 |
| 250-m | 2.5 | 0.2 | 18.5 | 2 | 3.85 | ||
| 300-m | 3 | 0.4 | 21 | 2.35 | 4.8 | ||
| 400-m | 4 | 0.4 | 21 | 3.3 | 4.8 | ||
| 500-m | 5 | 0.8 | 26 | 4.1 | 5.8 | ||
| 600-m | 6 | 0.8 | 26 | 5 | 5.8 | ||
更多产品及牌号推荐，欢迎咨询下载。
for more types and grade recommendation, welcome to contact us or download catalog.
